ペーパーショッピングバッグ油圧ホットフォイルスタンピングマシン

HH-TC4050LPTB

• 1. Hot plate area:400 ×500 mm
• 2. Working table area:520 ×800mm
• 3. Max printing pressure:20,000 Kg
• 4. Up and down distance:100mm
• 5. Heat wattage: 6×500W
• 6. Foil in feed: Motor Drive
• 7. Temperature adjustment:0-300oC .

HH-TC4060LPTB

• 1. Hot plate area:400 × 600 mm
• 2. Working table area:520 ×800mm
• 3. Max printing pressure:20,000 Kg
• 4. Up and down distance:100mm
• 5. Heat wattage: 6×500W
• 6. Foil in feed: Motor Drive
• 7. Temperature adjustment:0-300oC

• Professional design for shopping bag with insert-style workbench
• Bench made ofhigh strength cast steel forging, has a very high flatness and stability;
• Thread rising institutions to adjust the table lift to facilitate the opening and closing of space according to the height adjustment of the product tipping machine;
• Relay control program is running, easy operation, easy maintenance;
• Pairs of buttons control the stamping head up and down, security is greatly enhanced;
• Hydraulic drive instead of the pneumatic drive, stamping pressure significantly improve the stability is greatly enhanced;
• Heating pipe heating, rapid heating, replacement is simple and convenient;
• Heating plate can be removed to facilitate installation and replacement gilt template;
• Ironing board and table parallelism can be adjusted to facilitate the flexible adjustment depending on the size of the different regions of the pressure;
• Automatic temperature control system can be set depending on the product temperature, automatic temperature control; temperature control accuracy of about 5 degrees;
• Hot foil stamping degree of time and rolls of time can be set freely according to different technical requirements;
• Foil paper automatic document feeder, conveyor length can be set according to the size of the stamping area of freedom.
