空気圧ボトルスクリーンプリンター

共有へ:
単価: USD 3776 / Set/Sets
Min.Order 単価
1 Set/Sets USD 3776 / Set/Sets
お支払い方法の種類: L/C,T/T
Terms of Trade: FOB,CIF,EXW,FCA,CPT
最小注文数: 1
単価: USD
基本情報
モデル:S-220S
印刷版の種類: スクリーン印刷機
該当する業界: 農場, 小売り, 工事
保証対象外のサービス: ビデオテクニカルサポート, オンラインサポート, スペアパーツ, フィールドメンテナンスおよび修理サービス
ローカルサービスを提供する場所(海外のサービスアウトレットがある国): イタリア, ベトナム, ペルー, パキスタン, ロシア, 日本, モロッコ
ショールームの場所(海外にサンプルルームがある国): サウジアラビア, インド, スペイン, ケニア, チリ, アルジェリア, バングラデシュ, ウクライナ
状態: 新着
原産地: 中国
使用する: ラベルプリンター, ビルプリンター
自動化の程度: 半自動
色番号と表面番号の印刷: 単色
保証期間: 1年
コアセールスポイント: 低騒音レベル, マルチカラー
マーケティングタイプ: 普通品, 新製品2019
機械試験レポート: 提供
ビデオ工場検査: 提供
コアコンポーネントの保証期間: 1年
コアコンポーネント: PLC, エンジン
Additional Info
包装: 木製ケース
生産高: 50 sets / month
ブランド: KC
輸送方法: Ocean
原産地: ドンググアン
についてのサポート: 50 sets/month
認証 : CE Certificate
ポート: Shenzhen,Guangzhou,Hongkong
製品の説明

サンプルが表示されます

255

マシンの説明

S-220S Multi-function screen printing machine//Usage and characters

  • 220mm in diameter, suitable for printing less, hollow plastic bottles, hose, there is a slight taper of the hard and soft surface material color screen.
  • Used in baby bottles, cosmetic bottles, medicine bottles, filters, ignition and other hollow containers monochrome screen printing;
  • With surface UV curing machine M-1030UVS can be UV screen printing of plastic containers;
  • Solvent ink for screen printing, UV screen printing inks, screen printing ink printing a variety of functions;
  • Upper and lower part of table type surface screen printing machine, take place after the table automatically lifting the work piece;
  • You can use the foot switch for automatic operation, the safety factor greatly increased;
  • Multi-type screen printing machine, Both printing round objects and printing taper and flat objects, hardware replacement only way a simple gas conversion, will be able to achieve a multifunctional , and reduce costs.

Application

Plastics soft tubes, Bottles, containers, Bucket, Cosmetic case, any Cylinder-object, Oval-object.


S-220S Multi-function screen printing Machine //Parameters

  • Max. printing height: 320 mm;
  • Max. Printing diameter:;whole circle: 220 mm;.arc: 680 mm;
  • Max. printing speed: 1000 pcs/hr;
  • Air consume: 80 Litre/min(6bar).
  • Max Screen Frame: 850×450mm;
  • Stroke up-and-down of working table: 150mm;
  • Stroke up-and-down of Squeegee: 50mm;
  • Max length of printing objects: 400mm;
  • Range back-forth of Squeegee: 250mm;
  • Diameter of Fixture axis: 18mm;
  • Range back-forth of screen frame: 180mm
  • Works supply: 110V-220V Power supply;5-7 Bar compress air;
  • Package Dimension: 1130*1560*1360mm;
  • Gross weight: 190kg;
  • CBM: 2.3974
  • H.S.CODE: 8443198000
  • Certificate: CE


S-220S Multi-function screen printing Machine//Advantage

  • Choose clamp-type Workbench can be inflatable, or may not be blowing, can be placed all types of round, oval-shaped substrates;
  • Contact with the substrate , Working table up and down, to facilitate the placement of the substrates and removed;
  • High Precision axis control. Working table up and down, smooth running, accuracy up to 0.07mm;
  • High Precision axis control movement. Screen printing pressure is uniform and reliable, the accuracy up to 0.07mm;
  • Self-balance scraper technology and back blade, to ensure uniformity of ink, ink formation;
  • Microcomputer control program operations, set up a variety of modes;
  • Four counts digital LED count, high degree of automation;
  • Printed Stroke mechanical adjustments, adjust the speed of integrated circuit digital.
  • Around the screen frame, up and down the emblem of the tune, overlay accuracy, tuning and quick
